Partner
STMicroelectronics, Silicon Labs, Murata, Semtech
Tecnology core
MGM13P, STM32L082, SX1276
Form factor
60x68mm
Feature

Wireless module Silicon Labs MGM13P
CPU ARM Cortex-M4 40MHz
512 kB FLASH
64 kB RAM
Autonomous Hardware Crypto Accelerator and True Random Number Generator
Bluetooth 5.0 LE, Zigbee, Thread or multi-protocol connectivity compliant with Integrated antenna
CMWX1ZZABZ-078 LoRa®/Sigfox module (STM32L082 + SX1276)
4-Kbit Dynamic NFC / RFIDtag M24SR64-YMN6
Pressure sensor LPS22HB
Temperature & humidity sensor HTS221
Accelerometer & gyroscope sensor LSM6DSL
Four analog inputs
Four digital inputs
Push button
RGB LED
SPV1050 Ultra low power energy harvester and battery charger with embedded MPPT and LDOs
PV input up to 18V
battery input
12 poles screw connector
IP67 plastic housing available
